• Unique Feature
  ASRock Super Alloy
  - High Density Glass Fabric PCB
  ASRock Full Spike Protection
  ASRock Live Update & APP Shop
• CPU
  - Intel^® Quad-Core Processor J3455 (up to 2.3 GHz)
• Memory
  - Dual Channel DDR3/DDR3L Memory Technology
  - 2 x DDR3/DDR3L DIMM Slots*
  - Supports DDR3/DDR3L 1866/1600/1333 non-ECC, un-buffered memory
  - Max. capacity of system memory: 16GB**



  *2GB DRAM per module is not supported.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
  Intel^® Extreme Memory Profile (XMP) is not supported
• BIOS
  - 64Mb AMI UEFI Legal BIOS with GUI support
  - Supports Plug and Play
  - ACPI 5.0 compliant wake up events
  - Supports jumperfree
  - SMBIOS 3.0 support
• Graphics
  - Integrated Intel^® HD Graphics 500: 12 EUs inside (Up to 750MHz)
  - DirectX 12, Pixel Shader 5.0
  - Three graphics output options: D-Sub, DVI-D and HDMI
  - Supports Triple Monitor
  - Supports HDMI with max. resolution up to 4K x 2K (3840x2160) @ 30Hz or 2560x1600 @ 60Hz
  - Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz
  - Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz
  - Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports HW Accelerated Decoders: H.264 @ level 5.2, HEVC (H.265) 10b @MP level 5.1 (GPU accelerated), JPEG, VP8, VP9
  - Supports HDCP with DVI-D and HDMI Ports
  - Supports Full HD 1080p Blu-ray (BD) playback with DVI-D and HDMI Ports
• Audio
  - 7.1 CH HD Audio (Realtek ALC887 Audio Codec)*
  - Supports Surge Protection (ASRock Full Spike Protection)
  - ELNA Audio Caps



  *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Realtek RTL8111E
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
  - Supports LAN Cable Detection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Slots
  - 1 x PCI Express 2.0 x16 Slot (PCIE2: x1 mode)
  - 2 x PCI Express 2.0 x1 Slots
• Storage
  - 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
• Connector
  - 1 x Print Port Header
  - 2 x COM Port Headers
  - 1 x TPM Header
  - 1 x Chassis Intrusion and Speaker Header
  - 1 x CPU Fan Connector (3-pin)
  - 1 x Chassis Fan Connector (3-pin)
  - 1 x 24 pin ATX Power Connector
  - 1 x Front Panel Audio Connector
  - 1 x BIOS_PH Connector
  - 3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))
• Rear Panel I/O
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x D-Sub Port
  - 1 x DVI-D Port
  - 1 x HDMI Port
  - 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 2 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI
  Software
  - ASRock Power Gear*
  UEFI
  - ASRock Power Gear
  - ASRock Instant Flash
  - ASRock Internet Flash
  - ASRock Crashless BIOS



  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables
• Hardware Monitor
  - CPU, Chassis temperature sensing
  - CPU, Chassis Fan Tachometer
  - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
  - CPU, Chassis Fan multi-speed control
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  - Micro ATX Form Factor: 8.9-in x 7.0-in, 22.6 cm x 17.8 cm
  - Solid Capacitor design
• OS
  - Microsoft Windows^® 10 64-bit*
  - Linux: Ubuntu 16.10 / Fedora 25**



  *For the updated Windows^® 10 driver, please visit ASRock's website for details.

  **Linux O/S basic function support only, due to the compatibility of the Liunx system itself, there is no guarantee that all functions are supported.
• Certifications
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
