• Unique Feature
  ASRock Full Spike Protection
  ASRock Live Update & APP Shop
• CPU
  - Intel^® Quad-Core Processor N3150 (up to 2.08 GHz)
• Memory
  - Dual Channel DDR3/DDR3L Memory Technology
  - 2 x DDR3/DDR3L SO-DIMM Slots
  - Supports DDR3/DDR3L 1600/1066 non-ECC, un-buffered memory
  - Max. capacity of system memory: 16GB**



  *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.

  *If only one SO-DIMM module is installed, please install it into DDR3_A1.
• BIOS
  - 64Mb AMI UEFI Legal BIOS with GUI support
  - Supports Plug and Play
  - ACPI 5.0 Compliant wake up events
  - Supports jumperfree
  - SMBIOS 2.7 Support
• Graphics
  - Intel^® 8^th generation (Gen 8) graphics: up to 12 EUs inside
  - DirectX 11.1, Pixel Shader 5.0
  - Three graphics output options: D-Sub, HDMI and LVDS
  - Supports Triple Monitor
  - Supports HDMI with max. resolution up to 2560x1600 @ 60Hz
  - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
  - Supports LVDS with max. resolution up to 1920x1200 @ 60Hz
  - Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports HW Accelerated Decoders: H.264 @ level 5.2, H.265/HEVC @ level 5 (GPU accelerated), JPEG, VP8
  - Supports HDCP with HDMI Port
  - Supports Full HD 1080p Blu-ray (BD) playback with HDMI Port
• Audio
  - 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)*
  - Premium Blu-ray Audio support
  - Supports Surge Protection (ASRock Full Spike Protection)
  - ELNA Audio Caps



  *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
• LAN
  - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
  - Realtek RTL8111GR
  - Supports Wake-On-WAN
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection (ASRock Full Spike Protection)
  - Supports LAN Cable Detection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Slots
  - 1 x PCI Express 2.0 x1 Slot*
  - 1 x Half-size Mini-PCI Express Slot



  *Due to the power limitation and PCIe bandwidth (x1), the VGA card is not supported.
• Storage
  - 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
• Connector
  - 1 x Backlight Power Selection Jumper
  - 1 x Panel Power Selection Jumper
  - 1 x Backlight Control Header
  - 1 x Digital Input / Output Pin Header
  - 1 x Digital Input / Output Power Selection Jumper
  - 1 x Home Theater PC Header
  - 1 x Monitor Switch Header
  - 1 x Digital MIC Header
  - 1 x 3W Audio AMP Output Wafer Header
  - 1 x LVDS Connector
  - 1 x CIR Header
  - 1 x COM Port Header
  - 1 x Power LED Header
  - 1 x TPM Header
  - 1 x CPU Fan Connector (4-pin)
  - 1 x Chassis Fan Connector (4-pin)
  - 1 x SATA Power Connector
  - 1 x Internal Power Header
  - 1 x Front Panel Audio Connector
  - 1 x Analog Surround Audio Connector
  - 3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x USB 3.1 Gen1 Header by Etron EJ188 (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))
• Rear Panel I/O
  - 1 x DC Jack (Compatible with the 19V power adapter)
  - 1 x D-Sub Port
  - 1 x HDMI Port
  - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Microphone / Front Speaker (Supports SPDIF Optical)



  *Please use a 19V power adapter for the DC jack. his jack accepts dual barrel plugs with an inner diameter of 5.1 mm and an outer diameter of 7.4 mm, where the inner contact is +19 (±10%) VDC and the shell is GND.
• Software and UEFI
  Software
  - ASRock USB Key
  - ASRock XFast RAM
  - ASRock Restart to UEFI*
  UEFI
  - ASRock Power Gear
  - ASRock Instant Flash
  - ASRock Internet Flash
  - ASRock Crashless BIOS



  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Accessories
  - Quick Installation Guide, Support CD, I/O Shields
  - 2 x SATA Data Cables
  - 1 x SATA 1 to 2 Power Cable
  - 1 x WiFi Module Screw
• Hardware Monitor
  - CPU, Chassis temperature sensing
  - CPU, Chassis Fan Tachometer
  - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature)
  - CPU, Chassis Fan multi-speed control
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore
• Form Factor
  - Thin Mini-ITX Form Factor (Compatible with Mini-ITX)
  - Solid Capacitor design
  - High Density Glass Fabric PCB
• OS
  - Microsoft Windows^® 10 32-bit / 10 64-bit / 8.1 32-bit / 8.1 64-bit / 7 32-bit / 7 64-bit*
  - Linux: Ubuntu 14.04.3 LTS / Ubuntu 15.04 / Ubuntu 15.10 / Fedora 23 / Zorin OS 10 / Arch Linux 2015.10.01 / clonezilla-live-20150915-wily-amd64 / Android-x86-4.4-r3**



  *To install Windows^® 7 OS, a modified installation disk with xHCI drivers packed into the ISO file is required. Please see our online tutorial or check our User Manual for more detailed instructions.
  For the updated Windows^® 10 driver, please visit ASRock's website for details.

  **Linux O/S basic function support only, due to the compatibility of the Liunx system itself, there is no guarantee that all functions are supported.
• Certifications
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)
