• Unique Feature
  Alarm device
  - Buzzer (co-lay speaker)
  Internal selectors
  - 1x Clear CMOS selector
  - 1x ME UPDATE selector
  Super I/O
  - IT8625E/DX
  PCIe to PCI bridge IC
  - IT8892IX
• CPU
  - Intel^® Socket LGA1151
  - TDP 65W
• Chipset
  - Intel^® PCH H110
• Memory
  - Dual-channel, 2 Slots, Non-ECC, Unbuffered, 288 pin DDR4, Max. up to 32GB for all.
  - Types: 1866 MT/s (PC4-1866)
  2133 MT/s (PC4-2133
• BIOS
  - n/a
• Graphics
  - Integrated Graphics
• Audio
  - Realtek ALC662-VD(6-channel)
• LAN
  - Realtek RTL8111H Gigabit LAN
• Slots
  - 1x PCI Express slot (x16)
  - 2x PCI Express slot (x1)
  - 1x PCI Slot
  - 1x miniPCI Express slot (Supports half card & USB signal reserved.)
• Storage
  - 4x SATA III connectors
• Connector
  - Chassis Intrusion (1x2 pin)
  - CPU FAN (4 pin-PWM)
  - Chassis FAN (4 pin-PWM)
  - Intel^® Front Panel (2x5 pin)
  - Azalia Analog Front Audio (2x5 pin)
  - ATX power (24 pin)
  - ATX12V (4 pin)
  - COM port header (2x5 pin)
  - LPT header (2x13 pin)
  - TPM/TCM header (2x10 pin)
  - USB 2.0 header (2x5pin)
  - USB 3.0 header (2x10pin)
  - Mono-Out Header(Wafer 1x2pin)(w/ Amplifier)
• Rear Panel I/O
  - 1 x PS/2 Keyboard/Mouse
  - 1 x VGA port
  - 1 x DVI port
  - 1 x HDMI port
  - 1 x COM port
  - 4 x USB 2.0 ports *
  - 2 x USB 2.0 ports
  - 1 x LAN port (RJ45) + 2 x USB 3.0 ports
  - 1 x Audio I/O(3 ports, 6CH)



  *Optional to 5 x USB2.0 if miniPCIe mounted, * port invalid
• Software and UEFI
  - n/a
• Support CD
  - n/a
• Accessories
  DP to VGA bridge IC
  - RTD2168-CG
• Form Factor
  - n/a
• OS
  - n/a

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
